18
10. SPECIFICATIONS
FORK TRAVEL
WARNING! Specialized frames are compatible ONLY with forks that have a specific maximum amount of
travel (see table below). Use of different styled forks or forks with longer travel may result in catastrophic
failure of the frame which may result in serious personal injury or death.
MODEL
WHEEL
SIZE
FORK
TRAVEL
MODEL
WHEEL
SIZE
FORK
TRAVEL
FSR 6FATTIE 650B 140MM HARDTAIL 29 (SM) 29” 100MM
HARDTAIL 6FATTIE (SM) 650B 100MM HARDTAIL 29 (MD/LG/XL) 29” 120MM
HARDTAIL 6FATTIE (MD/LG/XL) 650B 120MM FAT 26” 100MM
BOLT SIZE / TORQUE SPECS
WARNING! Correct tightening force on fasteners (nuts, bolts, screws) on your bicycle is important
for your safety. If too little force is applied, the fastener may not hold securely. If too much force is
applied, the fastener can strip threads, stretch, deform or break. Either way, incorrect tightening
force can result in component failure, which can cause you to lose control and fall.
Where indicated, ensure that each bolt is torqued to specification. After your first ride, and
consistently thereafter, recheck the tightness of each bolt to ensure secure attachment of the
components. The following is a summary of torque specifications in this guide:
TORQUE SPECS (FSR PIVOTS):
PIVOT LOCATION IN-LBF Nm PIVOT LOCATION IN-LBF Nm
MAIN (BOTTOM BRACKET) 182 20.5 S-LINK @ SHOCK EXTENSION 148 16.7
DROPOUT 113 12.8 LOWER SHOCK MOUNT 175 19.8
S-LINK @ FRAME 96 10.8 UPPER SHOCK EYE 113 12.8
S-LINK @ SEATSTAY 130 14.7
TORQUE SPECS (GENERAL LOCATIONS):
LOCATION IN-LBF Nm LOCATION IN-LBF Nm
SEAT COLLAR 45 5.1 DERAILLEUR HANGER 35 4
SEATPOST @ SADDLE 120 13.5 WATER BOTTLE BOLTS 25 2.8
STEM @ STEERER TUBE 45 5.1 REAR DERAILLEUR 70 7.9
STEM @ HANDLEBAR 45 5.1 SHIFTERS 25 2.8
CRANK BOLTS 443 50 BRAKE LEVERS 22 2.5
CHAINRING BOLTS 89 10* REAR BRAKE GUIDES 6 0.7
SPIDER LOCKRING 443 50 BATTERY AXLE 88.5 10
CAUTION: Ensure all contact surfaces are clean and bolt threads are greased or have a
threadlocking compound (refer to the instructions for each bolt) prior to installation.
* Apply blue loctite to chainring bolts.
