22
At 10% battery charge remaining, the system will start to reduce the amount of support. At 1%, the system switches
off the motor support.
If your bicycle is at a standstill for at least 10 minutes, the Battery Management System will switch the system off. In
order to continue riding with support, you have to switch the system on again.
80-100%
60-79%
40-59%
20-39%
0-19%
6
9.4. INSTALLING THE BATTERY
7
BATTERY
CONNECTOR
CAUTION: ALWAYS
TURN OFF THE
BATTERY BEFORE
INSTALLING OR
REMOVING!
Lower the bottom edge of the battery into the bottom of the battery cavity (fig.7), then align the top of the battery
with the top of the cavity.
The key does not need to be in the lock to install the battery. The battery will lock in place
automatically when installed. The key is required only to remove the battery.
