SPECTRA 1759EX 35
9.19 ZONE RESTORE REPORT OPTIONS
Section [132]: Zone Options
Option [6] OFF = Report On Bell Cut-Off (default)
Option [6] ON = Report On Zone Closure
With option [6] OFF, the control panel will send the Zone Alarm Restore report codes (see page 30) to the central station when the
zone has returned to normal and the Bell Cut-Off Timer has elapsed (see page 26). With option [6] ON, the control panel will send
the Zone Alarm Restore report codes to the central station as soon as the zone returns to normal or when the system is disarmed.
9.20 TELEPHONE LINE MONITORING (TLM)
When enabled, the system verifies the existence of a telephone line once every second. A line test failure occurs when the TLM
detects less than 3 volts for the period defined by the TLM Fail Timer. If the line test fails, the control panel’s
STATUS LED flashes
and generates one or more conditions as defined by the TLM settings below. These will be restored when the control panel
detects the telephone line again. Please note that when the dialer detects an incoming call, the TLM test will stop for 1 minute.
Section [135]: Dialer Options
[1] OFF / [2] OFF: TLM Disabled
[1] OFF / [2] ON: Trouble Only
Upon line test failure, a TLM Trouble will appear in the keypads’ Trouble Display (see page 42).
[1] ON / [2] OFF: Alarm If System Armed
Upon line test failure, a TLM Trouble will appear in the keypads’ Trouble Display (see page 42) and if the system is armed, the
control panel will generate an alarm.
[1] ON / [2] ON: Silent Alarm Becomes Audible
Upon line test failure, a TLM Trouble will appear in the keypads’ Trouble Display (see page 42) and causes a silent zone or silent
panic alarm to switch to audible.
9.20.1 TLM FAIL TIMER
Section [079]
016 to 255 x 2 seconds, Default = 32 seconds
If TLM does not detect the existence of a telephone line for the duration of this period, the control panel will generate
the condition(s) defined by the TLM options (see above).
PART 10: PROGRAMMABLE OUTPUTS
A PGM is a programmable output that toggles to its opposite state (i.e. a normally open PGM will close) when a specific event has occurred
in the system. For example, a PGM can be used to reset smoke detectors, activate bells or strobe lights, open/close garage doors and
much more. When a PGM closes, the control panel supplies a ground to the PGM activating any device or relay connected to it. When a
PGM opens, the circuit opens from ground, therefore, cutting power to any devices connected to it.
PGM1
A programmable output that provides
up to 150mA.
Refer to
Alarm Relay and PGMs on page 5.
PGM2
PGM2 is a programmable output that can provide up to 1A. PGM2 is designed to be used as a Strobe Output. For information refer to PGM
Strobe Options on page 36. For connections, refer to Alarm Relay and PGMs on page 5.
Global PGM
The Global PGM allows you to use the control panel’s PGM Event List to activate PGMs located on a module or LCD keypad. For example,
if you enable a module’s “Follows Global PGM” option, the PGM on the module will activate whenever the event programmed in section [124]
occurs. Every PGM on every keypad and/or expansion bus module can be programmed to follow the event(s) defined by the Global PGM.
10.1 PGM ACTIVATION EVENT
Sections [120], [122], and [124]
This feature allows you to program the control panel to activate a PGM when a specific event occurs in the system. The PGM will
remain in its active state until the programmed PGM Deactivation Event occurs or when the PGM Delay period elapses (see
page 36). For the Event List see the PGM Table in the Spectra 1759EX Programming Guide. To program a PGM Activation Event:
1) Enter section that represents the desired PGM. PGM1 = [120], PGM2 = [122], Global PGM = [124]
2) Enter the Event Group #.
3) Enter the Sub-Group #.
4) Enter the Partition # (01 = Partition 1; 02 = Partition 2; 99 = Both Partitions)
