INSTALLATIONS
MB720 User’s Manual 11
Connectors on MB720
The connectors on MB720 allows you to connect external devices such
as keyboard, floppy disk drives, hard disk drives, printers, etc. The
following table lists the connectors on MB720 and their respective
functions.
Connector Locations on MB720 .................................................. 12
FDD1: Floppy Drive Connector................................................... 13
IDE1, IDE2: Secondary and Primary IDE Connectors ................ 13
FAN1: System Fan Power Connector .......................................... 14
FAN2: CPU Fan Power Connector .............................................. 14
CN1: ATX Power Supply Connector........................................... 15
CN2, CN3: Serial ATA (SATA) Connectors ............................... 15
CN4: Mini PCI Connector............................................................ 15
CN5: Parallel Port Connector....................................................... 15
CN6: RJ45 and 2 USB Ports ........................................................ 16
CN7: Line Out, Line In, Mic Connector ...................................... 16
CN8: COM1 Serial Port ............................................................... 16
CN9: RJ45 Connector for LAN1 (10/100)................................... 16
CN10, J12: TV out Connector (RCA Jack/CN10 and 3-pin
Header/J12) .................................................................................. 16
CN11: VGA CRT connector ........................................................ 17
J1: System Function Connector.................................................... 17
J2: LVDS Panel Interface (used with ID380 Card, not in A1
version)......................................................................................... 19
J3, J4: USB Connector (USB3/USB4, USB5/USB6)................... 19
J7: IrDA Connector ...................................................................... 19
J8: Digital 4-in 4-out I/O Connector ............................................ 19
J10: CD-In Audio Connector ....................................................... 20
J11: Serial Ports............................................................................ 20
PS2-KBMS1: PS/2 Keyboard and Mouse Connectors................. 20
