The unit is intended for measuring distances, lengths, heights, spacings
and to calculate areas and volumes. The unit is suitable for measuring in
interior and exterior construction.
Please open the fold-out page with the illustration of the unit and leave it
open while you read these operating instructions.
1
Continuous measurement button/
minimum-maximum measurement
2
Length measurement button
3
Bubble level*
4
Aligning aid
5
Area measurement button
6 “on/off”
button
7
Measurement button
(Two-step button for sighting and measuring)
8
Display
9
Display lighting button
Symbols
Symbol Name Meaning
mm Millimeter Length
m Meter Length
m
2
Square meter Area
m
3
Cubic meter Volume
in Inch Length
ft Foot Length
sq.ft Square feet Area
cu.ft Cubic feet Volume
s Seconds Time
min Minutes Time
°F Degrees Fahrenheit Temperature
°C Degrees Celsius Temperature
nm Nanometer Wave length
mW Milliwatt Power
V Volts Voltage
g Gram Mass
oz Ounce Mass
° Degree Angle
EN European standard
IP Protection class
Intended Use
Product Elements
