8) Using a Phillips head screw driver lightly tighten the bulb clamp screws. Try and
spin the bulb a little after tighten. If there is no movement then move on to the
next step. However if the bulb moves tighten the clamp screw until the bulb is not
free to move.
9) Re-install the bulb housing and tighten down the #4-40 housing screw so they
are hand tight.
10)Replace the probe cover by reinstalling the 6 #2-56 screws.
Gasket
The handheld contact probe is shipped with a thick rubber gasket which surrounds
the sapphire window and prevents cracking of the window and damage to the
surrounding aluminum. The gasket presses on to the front of the contact probe, and
may be removed by pulling gently on one of the tabs on the gasket.
Specifications
Input: 5.5-9 V, 2A minimum
Bulb: Halogen, 4.25 V, 1.06A, ~650 life hours, Color Temp 3,000°K
Information and Warnings
WARNINGS:
The contact probe will become hot after extended use, to avoid this turn off the probe
when not taking scans with it. Turning off the bulb while not in use also extends both
battery charge and the overall life of the bulb.
Do not place any combustible materials in the contact probe sampling area for a long
period of time.
