Spectrum DSP M2 User Manual

Spectrum DSP M2 User Manual V1.1
Typical installations
Concept – Xiegu G90 to wide DSP
The Xiegu G90 is an excellent and
feature-packed HF transceiver that's
key limitation is it's small display. By
the addition of the Spectrum DSP that
small display is converted into the
Zoom window, showing a close up of
the stations nearest to tune frequency.
Perfectly synchronized via the CAT
connection, the Spectrum DSP
becomes part of the station to provide
not only a wide-band spectrum window
that's zoomable from 3 to 192 Khz, but
also an independent 192 Khz tuning
window, where with the drag of the
stylus, you can instantly listen to
stations without having to spin the dial.
When you find the station you want,
one click is all it takes to synchronize
the G90. DSP noise & notch filtering are
also provided.
This combination results in a better
option that upgrading to many of the
newer DSP transceivers with larger
screens that often lack items such as
the ATU and full 20W output.
Concept – Elecraft KX3 and KX2 to wide DSP
The classic Elecraft KX2 and KX3, with it's beautiful smooth turning dial, synchronizes
perfectly to the Spectrum DSP, providing an independent 192 Khz of instant tuning across the
band with the stylus or a light touch on the screen. When you find the station that you want,
one click synchronizes the Elecraft ready for operation. The Spectrum allows you to view the
whole band, zooming from 3 right out to 192 KHz, and providing bidirectional tuning
synchronization for the fastest access to stations across the bands.
P 3

Spectrum DSP M2 Specifications

General

Brand	Spectrum
Model	DSP M2
Category	Test Equipment
Language	English
