2.6 Camera Installation（Optional）
2.6.1 Windshield
1. Thread the camera's wire through the hole on the adhesive
bracket, and secure the camera tightly to the bracket.
2.Peel off the protective film from the adhesive bracket, and attach
the bracket to the vehicle's front windshield. Press firmly to
ensure it adheres securely.
3.Use the camera extension cable to connect the camera to the
device.
4.Adjust the angle of the lens.
Note
Depending on the vehicle, the cigarette lighter socket may be located
in a different position. The figure provided is for reference only.
2.5 Device Installation
Insert the power cable into the car cigarette lighter, and connect
the other end to the power interface of the device.
