Check that the wiring is completed for:
Please use the screws provided.
Ensure the orientation arrow is
pointing upwards.
You are ready to secure the rear housing to the wall box.
Power terminals.
Sensor terminals (if applicable).
Communication connections (optional but recommended).
20
JGSTAT2 Instruction Manual
Installation - Thermostat Mounting
1
2
3
