Model JGSTAT2W or JGSTAT2B
Type Electronic programmable room thermostat, digital room
thermostat and hot water timer designed for 230v AC applications
Programming Modes User selectable for 5/2, ALL and Individual day options
Program Number 1-6 Selectable
Modes Party, Vacation, Program and Frost
Override Permanent and temporary
Frost Protection 5ºC Adjustable.
Power Source 230v AC 50Hz
Rating 3 Amp
Communication Bus 12v DC
Temperature Scale 5ºC to 35ºC, tolerance 0.5ºC
Heat/Cool Global changeover using communication bus and external input
to the wiring centre
Sensor Air or floor protection. Cylinder thermostat when configured for
hot water timer
Device Parameters See page 41 - 42 for full list of functions
Operating Temperature 0ºC to 50ºC
Storage Temperature -20ºC to 60ºC
44
JGSTAT2 Instruction Manual
Installation - Technical Detail
