Speedfit JGSTAT2W - Installation - Hot Water Timer Cylinder Thermostat

ZONE 1
SL N L SL N L SL N L SL N L SL N L SL N L SL N LSL N L
ZONE 2 ZONE 3 ZONE 4 ZONE 5
ZONE 6 ZONE 7
ZONE 8
5 x 20mm
5 x 20mm
ZONE 1
SL N L SL N L SL N L SL N L SL N L SL N L SL N LSL N L
ZONE 2 ZONE 3 ZONE 4 ZONE 5
ZONE 6 ZONE 7
ZONE 8
5 x 20mm
5 x 20mm
Note: Optional - The JGSTAT2 can be configured for a connection to a cylinder
thermostat. Please see Device Parameters on page 40. For additional wiring
centre information refer to the Wiring Centre Instruction Manual.
IN OUT
HW Timer connected
to cylinder thermostat.
Link must
be fitted
IN OUT
WC connected cylinder
to thermostat (Default).
Cylinder thermostat
19
www.speedfitUFH.co.uk
Installation - Hot Water Timer Cylinder Thermostat
INSTALLATION
