JGSTAT2 Instruction Manual
Installation - LCD Graphics
ICON FUNCTION
Box: Indicates selected mode e.g. means the current
setpoint is Hi temp, means the Hi temp is not selected.
Sunny: Hi comfortable temperature.
Cloudy: Middle comfortable temperature.
Moon: Low comfortable temperature.
Programmable Thermostat program mode indicator:
Indicates program is running, Auto On or Auto Off. For Group
Thermostat this indicates that it is a member of a group.
Party indicator: When Party Mode is active.
Holiday indicator: When Holiday Mode is active.
Frost protection indicator: Frost Protection is active, not
available
in Cooling Mode (if applicable).
