24
JGSTAT2 Instruction Manual
Installation - LCD Graphics
ICON FUNCTION
Hot Water (HW) indicator: Unit operating as a hot water timer.
Hot Water (HW) indicator: Indicates demand for hot water.
HW Program mode indicator: Indicates program is running.
HW Mode indicator: Mode for 1 period of HW a day, from
Program 1 ON to Program 3 OFF.
HW Mode indicator: Hot water switched on (continuously).
HW Mode indicator: Hot water switched off (continuously).
HW Mode indicator: Indicates Boost +1hr override.
