SpeedTech Lights K-FORCE 36 - Wiring and Specifications; Wiring Diagram; AUX Wiring Diagram; Specifications

4 SpeedTech Lights, Inc © 2019
K-FORCE
®
36
FULL LIGHT BAR
Wiring Diagram
Wire Color Function
Red (Thick)*
Positive
Black (Thick)*
Negative
Brown
Forward Facing Lights
Light Blue
Rear Facing Lights
Purple
Full 360° Warning Lights
Yellow
Flash Pattern
Light Green
Take Down
Green
Alley
* Indicates a main power cable.
Wire Color Function
Blue
Left Arrow
White
Center Out Arrow
Orange
Right Arrow
Grey
Cruise Lights (4 Corners)
Red (Thin)*
Control Box In Positive
Black (Thin)*
Control Box In Negative
Pink (Thin)*
Control Box Out Positive
Yellow/Green (Thin)*
Control Box Out Negative
NOTE: All cables except Negative contact +12 VDC.
Specications
Voltage 12 VDC
Amps < 12.6
Optic TIR / Linear
LED Count TIR: 72 / Linear: 108
Cable Length 13’ Light Bar Cable, 8’ Power Cable, 8’ AUX Cable
Flash Patterns 45
AUX Wiring Diagram
Wire Color Function
Red
AUX Positive
Blue
AUX Negative
