K-FORCE
®
36
FULL LIGHT BAR
Supreme Control Switch Box Operation (Sold Separately)
Slide Switch:
• O󰀨 position: Turns o󰀨 warning functions of the Light Bar.
• 1st position: Powers only the front of the Bar and forward facing 45° warning modules.
• 2nd position: Powers only the back of the Bar and rear facing 45° warning modules.
• 3rd position: Powers all warning functions of the Light Bar.
Take Down Button*:
• 1st press: Steady Burn.
• 2nd press: Flashing.
• 3rd press: Flash in the same sequence/ash as the active warning pattern.
Alley Button*:
• 1st press: Steady Burn.
• 2nd press: Flashing.
• 3rd press: Flash in the same sequence/ash as the active warning pattern.
Tra󰀩c Advisor Buttons*:
• Tra󰀩c Advisor LEDs will ash in sequence with warning mode when not activated.
• Left Arrow: Right to Left Tra󰀩c Sweep.
• Center Out Arrow: Center Out Tra󰀩c Sweep.
• Right Arrow: Left to Right Tra󰀩c Sweep.
Flash Pattern Button:
• Cycles to the next ash pattern with each press.
• Non-Volatile memory recalls the last ash pattern selected.
• Hold for 3 seconds to toggle Steady Burn mode.
• Hold for 5 seconds to toggle Random pattern mode.
Cruise Button (45° (Four Corner) Modules)*:
• 1st press: Steady Burn.
• 2nd press: Flashing.
• 3rd press: Flash in the same sequence/ash as the active warning pattern.
AUX Button*:
• Toggle power to AUX cables On and O󰀨.
Back Plate Mount:
• Included with Supreme Control Switch Box purchase.
* Warning lights do not need to be activated for these Buttons to function.
Extension Cable (Sold Separately)
• If you have an extension cable with connectors, connect the corresponding ends to
one another. Use the connector at the end of the cable to plug into the control box.
• If you have an extension cable with one connector, you will need to cut the connector
o󰀨 of the main cable harness coming out of the Light Bar. Save it as a spare part.
You will solder and heat shrink each wire within the cable harness to each wire in the
extension cable harness. DO NOT cross connect wires. Use the connector at the end
of the extension cable to plug into the control box.
• If you have an extension cable with no connectors, you will need to cut in the middle
of the main cable harness coming out of the Light Bar. You will solder and heat shrink
each wire within the cable harness to each wire in the extension cable harness. DO
NOT cross connect wires. Use the reattached connector from the end of the main
cable harness to plug into the control box.
• NOTE: DO NOT leave connectors, cables, solder points exposed to heat, moisture, or
debris.
