Spektrum AR710012
EN
Optional Charge ON/OFF Adaptor Lead
Included with the system is an optional charge, ON/OFF adaptor lead.
Some heli pilots may prefer to use this adaptor lead instead of the
included Soft Switch. When plugged into the receiver’s switch port this
adaptor lead allows the following:
• The battery can be charged through the adaptor lead.
• The system can be turned off by inserting the bind plug. Removing the
bind plug turns the system on.
• Battery voltage can be monitored through the adaptor lead using a
Flight Log or voltmeter. If the voltmeter is plugged directly into the
male-male extension, the system is active and voltage under load
(system operational) is displayed. If plugged into the charging lead, the
at-rest battery voltage is displayed.
Install the adaptor lead as shown to the right.
