17SPEKTRUM DX3R PRO USER GUIDE
EN
•Highlightthedesiredswitch/
button and press the roller. Use
the roller to select the desired
function from the list above.
•Note: A positive or negative
value is available for many of
the above functions allowing the
reversing of the switch direction.
User Name
You can program a user name with up to ten characters.
The name will display on the main screen.
•IntheSystemscreenhighlight
the User Name and press the
roller to access the function.
•Usetherollertoselectthe
position, then press the roller to
access the character.
Display
The Display screen allows you to adjust the backlight,
main screen, and languages.
Contrast:
The contrast can be set to a value from 0–30, 0 is the
lightest, 30 is the darkest, default is 10.
Light:
You can set the backlight to one of three modes:
Timer, On or Off.
•Timer:Thebacklightwillturn
off after a preset delay (set by
the Timeout value). Press any
button to reset the delay.
•On:Thebacklightneverturns
off when the transmitter is on.
•Off:Thebacklightisalwaysoff.
•UsetherollingtoaccessLight.
•Presstherollerandthe
surrounding box will flash.
•Rotatetherollertothedesiredbacklightmodeand
press the roller to select it.
Timeout:
The amount of time the light stays on before turning
off when Light is set to Timer. The timeout can be set
from 1 (default) to 10 seconds.
Main:
You can change the brake percent display at the bottom
of the main screen to display the Aux channel position
or the dig position, for crawlers equipped with a dig
transmission.
Brake: Brake percent
Aux: Aux channel position
Dig: Dig transmission position indicator
•IntheDisplayscreen,highlightMainandpressthe
roller.
•Usetherollertoselectthedesiredfunctionfromthelist
above. Press the roller to save the settings .
Language:
The DX3R PRO can display the screen text in one of four
languages: English (default), German, French, and Italian.
Use the roller and select the Language function.
•Presstherollerandthesurroundingboxwillash.
•Rotatetherollertothedesiredlanguageandpressthe
roller to select it.
Alerts
This function allows the type of alert for each model to be
set. The alert type can be none, tone, vibrate, or both tone
and vibrate.
•UsetherollerandselecttheAlerts
function.
•PresstherollerandtheAlerts
screen displays.
•Rotatetherollertothedesiredalert
and press the roller to select it.
•Rotatetherollertousethealert
type and press the roller to select it.
•VoltageAlert:TheVoltageAlertsetsthevoltage
threshold of the transmitter batteries at which the alarm
sounds. The default setting is 4.0 volts. If you wish
to change this setting, the first click of the roller will
highlight the Voltage Alert value. Rotate the roller to
adjust the voltage threshold from 0.0 to 6.5 volts.
Switch
User Name
01: Model 01
A-Thr Trim +
B-Str Trim +
C-Aux Lin
D-Str S/R +
E-Brake +
F-Timer
System
Switch Select
A B C D E F
Username:
◊
Display
Alerts
RF Mode: STD
User Name
Display
User Name
01: Model 01
Contrast: 10
Timeout: 5
Main: Brake
Lang: EN
Light: On
Alerts
User Name
01: Model 01
TX:
4.0v Tone
Timers: Vibe
Telemetry:
Temp: Tone
Batt: None
