Spencer CROSS - Model-Specific Components and Characteristics; CROSS UP 8409 Components and Specs; CROSS CHAIR;CROSSOVER CHAIR Components

7
16
Rear wheel with bracket
PU
23
Backrest piston
Steel
17
Front wheel
PU
24
Backrest
PE
Feature
Dimension
Length (mm)
1970
Width (mm)
570
Loading trolley underwheel height (cm)
From 58 to 70 ± 1
Patient bed height with stretcher in position on the ground
2
30 ± 1
Patient bed height with stretcher in the intermediate position
2
66 ± 1
Patient bed height with stretcher raised
2
88 ± 1
Wheel diameter (mm)
Ø 200±5%
Load capacity (kg)
170 kg (250kg Crossover model)
Weight
without standard accessories
(kg)
45
CROSS UP 8409
See Callout Image P4
No.
Description
Material
No.
Description
Material
1
Telescopic handle slide unlocking
button
Nylon
6
Reclining backrest
Polyethylene
2
Trendelenburg/Fowler mechanism
Steel
7
Folding sidebar
Nylon,
Aluminium, Steel
3
Sidebar unlocking lever
Nylon
8
Foot side board
Polyethylene
4
Framework
Aluminium
9
Footrest
Polyethylene
5
Wheels
PU
See Callout Image P5
No.
Description
Material
No.
Description
Material
10
Rear leg unlocking handle
Nylon-coated steel
18
Front wheels
PU
11
Front leg unlocking handle
Nylon-coated steel
19
Front legs
Steel
12
Rear lock system
Steel Nylon,
Aluminium
20
Variable height control lever
Nylon
13
Rear wheel with bracket
PU
21
Loading trolley wheel
PU
14
Brake
Chrome-plated FE
22
Stops for Cross Up 8409 stretcher
Steel, Nylon
15
Rear leg lifting piston
Steel
23
Front wheel unlocking lever (TWIST
version only)
Polyethylene
16
Rear legs
Steel
24
Stretcher release lever
Nylon
17
Front leg lifting piston
Steel
Characteristics
CROSS UP 8409
CROSS UP 8409 TWIST
Width (mm)
570
570
Length (mm)
1970
1970
Sidebar length (mm)
680
680
Sidebar height (mm)
200
200
Trolley Wheel diameter (mm)
200
200
Stretcher Wheel diameter (mm)
100
100
Weight (kg)
47
49
Maximum load capacity (kg)
250
250
CROSS CHAIR – CROSSOVER CHAIR
See Callout Image P6
No.
Description
Material
No.
Description
Material
1
Front handles
Steel
10
Trendelenburg selection mechanism
Steel
2
Backrest
PE
11
Configuration unlocking lever
Nylon
3
Framework
Al
12
Rear wheels ø 150
PU
4
Sidebar
Al,Nylon,Steel
13
Trolley fixing bar
Steel
5
Chair frame
Steel
14
Chair frame
Steel
6
Lifting piston
Steel
15
Rear handles
Steel
7
Piston control rod
Steel
16
Sidebar opening levers
Nylon/Steel
8
Rear handles
Steel
17
Front wheels
PU
9
Pivoting wheels with brake
PP/Nylon
18
Backrest piston rod
Nylon
