Spencer CROSS - Troubleshooting Common Issues; Problem Resolution Table

18
The stretcher is used with a
fastener that does not provide
automatic release.
If necessary, request a different fixing system.
The Cross Chair configuration change system is
not working properly or is difficult to operate.
The moving mechanisms are
damaged.
Immediately remove the device from service and
contact the service centre.
Parts not lubricated.
Clean and lubricate as described in the operating
instructions.
Damaged rear handle locks.
Immediately remove the device from service and
contact the service centre.
The attachment of the stretcher to the trolley is
not secure.
Wear or damage of the
components that constitute the
locking mechanisms.
Immediately remove the device from service and
contact the service centre.
In Cross Chair in chair mode, the backrest does
not remain in the upright position.
The lock has not been inserted in
the vertical position.
Using the rod, check that the lock has been inserted
in the correct position.
The locking systems are worn.
Immediately remove the device from service and
contact the service centre.
It is not possible to lift Cross Chair in stretcher
mode because the frame bends.
The configuration lock does not
engage.
Check that the pull-out handles reach Position 1. If
the problem persists, contact the service centre.
In Cross Chair, it is not possible to switch from
chair mode to stretcher mode.
The rear telescopic handles have
been moved to Position 1 during
use in chair mode.
Move the rear telescopic handles to Position 2 and
proceed with the configuration change.
14. ACCESSORIES
ST42706C
10G SENSOR LOCK FIXING SYSTEM
ST42702C
Hook R-MAX B certified 10G
IF01047C
TRACK 4-30 – TELESCOPIC IV HOLDER
EN90003C
END-T 10G INSTRUMENTS TABLE
CB09028C
TANKER FIXING SUPPORT FOR SAFEBAR
CB09025C
TANKER YELLOW OXY. TANK HOLDER FOR STRETCHER SIDERAIL FIXING
ST00491A
STX 90 TELESCOPIC HEADREST FOR STRETCHERS
CR90010B
Adapter for loading trolley wheels
CR90011B
S-MAX/HUX LOADING TROLLEY EXTENDER
CR90012C
LOADING TROLLEY ADAPTER FOR S-MAX/HUX
ST70002A
STX 702 Two piece metal black reflex strap, black
ST70000A
QMX 777 Anatomical segmented, watertight mattress, black
ST70005A
QMX 777 Anatomical segmented, watertight mattress, yellow
ST70004A
QMX 777 Anatomical segmented, watertight mattress, orange
ST70019A
QMX 777 Anatomical segmented, watertight mattress, green
ST70020A
QMX 777 Anatomical segmented, watertight mattress, blue
ST70018A
QMX 777 Anatomical segmented, watertight mattress, black
ST70006A
Mattress fastening strap
CB09025C
Tanker yellow oxygen tank for stretcher siderail fixing
CB09026C
Siderail fixing support for tanker oxygen tank
ST00497B
DNA Strap chest strap with re-winding system
ST00498B
DNA Strap with re-winding system
ST00499B
STX 499 - UNIVERS ADJUST. 4-PC. CHEST STRAP
ST00592A
STX 592 - YELLOW METAL 2-PC. METAL HOOK STRAP
CR90021B
Ø60×25 wheel kit for top loading exceeding 670 mm
15. SPARE PARTS
ST70002A
STX 702 Two piece metal black reflex strap, black
ST70000A
QMX 777 Anatomical segmented, watertight mattress, black
ST70005A
QMX 777 Anatomical segmented, watertight mattress, yellow
ST70004A
QMX 777 Anatomical segmented, watertight mattress, orange
ST70019A
QMX 777 Anatomical segmented, watertight mattress, green
ST70020A
QMX 777 Anatomical segmented, watertight mattress, blue
ST70018A
QMX 777 Anatomical segmented, watertight mattress, black
ST00499B
STX 499 - UNIVERS ADJUST. 4-PC. CHEST STRAP
