Air Refreshment Mode
The system controls one motorized air flap. There are two system operation modes:
- Smart Air
- Manual Mode
The Air Refreshment damper operates at both modes. The Smart Air mode automatically controls
according to the temperature conditions (internal, external and for renovating the air inside the vehicle).
The Manual Mode allows the driver to control the opening of external air manually. When the Automatic
Control Mode is activated, it is selected Smart Air, indicated at the panel by the least significant digital
point from the display. This operation enables the damper to operate in a way that it always seeks for the
best comfort and thermal balance conditions as well saving fuel.
To change the damper state, press the Air Refreshment Key and the panel will shows the damper state:
- = open and = closed
When the damper state is shown, press the Temperature Increase Key to open or the Temperature
Degrease Key to close the damper door. The display point will turn off and the Manual Mode is taken
over. After the elapsed time of the parameter (in minutes), the system came back to operate in the
Smart Air mode.
In the Smart Air mode, the fresh air flap opens and closes automatically and the cycle is according to the
parameters (time opened in seconds) and (time closed in minutes). This will just happen when the
internal temperature is between 3ºC over Set-point and 3ºC below Set-point. When the internal
temperature is below 15ºC in cool mode, the system tries to cool down only with fresh air. The clutch
waits 1 minute to engage. After elapsed this time the system checks if temperature reduces at least one
degree. These are repeated until the temperature did not reduce 1ºC each minute, then the clutch is
engaged.
In the Manual Mode the damper state is indicated by the AIR RENOVATION led (only when opened).
5.11. Air Refreshment Mode
