3. THE POWER AMP AT A GLANCE
Front panel
1. STANDBY: To switch the component on and
off.
2. PROTECT LED: Normally off. When blinking
red it indicates that the protection circuit is
active
3. STANDBY LED: Indicates the selected
function:
stand-by red
amp on off
4. POWER LED: Indicates the selected function:
stand-by off
amp on red
POWER
STANDBY
PROTECT
1
2
3
4
