SPHINX Project Twelve Service Manual
21
Designator Part Type Description
R33 10R/5W Resistor 5W
R34 10R/5W Resistor 5W
R35 220R Resistor
R36 100R Resistor
R37 100R Resistor
R38 0.22R Resistor 5W
R38 68R Resistor
R4 18K Resistor
R40 0.22R Resistor 5W
R41 100R Resistor
R42 68R Resistor
R43 0.22R Resistor 5W
R44 22K Resistor
R45 0.22R Resistor 5W
R46 604R Resistor
R48 470R / 2W Resistor 2W
R49 470R / 2W Resistor 2W
R5 22K Resistor
R50 470R / 2W Resistor 2W
R51 470R / 2W Resistor 2W
R6 120K Resistor
R7 820R Resistor
R8 820R Resistor
R9 22R Resistor
RL1 REL1 Relay
