SPHINX Project Twelve Service Manual
22
Partlist protection
Designator Part Type Description
C201 10µ/25V Electrolitic capacitor
C203 100n MKT capacitor
C203 100n MKT capacitor
C204 100n MKT capacitor
C206 100n MKT capacitor
C207 100n MKT capacitor
C208 1n MKT capacitor
C209 1µ5/16V Electrolitic capacitor
C210 100n MKT capacitor
C211 100n MKT capacitor
C212 100n MKT capacitor
C213 100n MKT capacitor
C214 100n MKT capacitor
C215 100n MKT capacitor
C216 100n MKT capacitor
C217 100n MKT capacitor
C218 100n MKT capacitor
C219 330µ/6V3 Electrolitic capacitor
C220 100n MKT capacitor
D201 OPTOUT optical output
D202 1N4148 DIODE
D203 BYD77 DIODE
D204 1N4148 DIODE
D205 1N4148 DIODE
D206 5V1 ZENER DIODE
D207 5V1 ZENER DIODE
IC201 LM7805 Voltage regulator
IC282 PIC16C71 Microcontroller
Q201 OPTIN optical output
Q202 BC879 Transistor
Q203 BC807 Transistor
Q204 BC807 Transistor
R1 314R Resistor
R2 2k2 Resistor
R201 4k7 Resistor
R202 4k7 Resistor
R203 4k7 Resistor
R204 4k7 Resistor
R205 10k Resistor
R206 47k Resistor
R207 4k7 Resistor
R208 4k7 Resistor
R209 560R Resistor
R210 560R Resistor
