SPHINX Project Twelve Service Manual
23
Designator Part Type Description
R211 560R Resistor
R212 100k Resistor
R213 560R Resistor
R214 2k2 Resistor
R215 2k2 Resistor
R216 2k2 Resistor
R217 4k7 Resistor
R218 10k Resistor
R219 4k7 Resistor
R220 1M Resistor
R221 10k Resistor
R222 10k Resistor
R223 390R Resistor
R224 390R Resistor
R225 1k Resistor
R226 4k7 Resistor
R227 1k Resistor
R228 1k Resistor
R229 4k7 Resistor
R230 390R Resistor
R231 390R Resistor
R232 10k Resistor
R233 4k7 Resistor
R234 4k7 Resistor
R235 1k Resistor
R3 22k2 Resistor
REL1 MT2 6V Relay
S1 SHA-2XWIS Switch
U200 LM324 Quad OPAMP
©1998 Audioscript BV
Version: 3-09-1998
