17
.
Exchange the drier filter every 100/150 working hours of the recovery compressor or at least every 2 years
even when the station is not in continuous use.
1) Separate the rear panel from the station.
2) Unscrew the filter slowly and carefully.
3) Install the new filter (in considering of the
direction).
Attention: Do not dispose of the filter with normal waste but with special waste according to the law.
Art. Exchange of de-oiling filter
Maintenance of oil discharging filter.
The oil-discharging filter has to be cleaned every time the dryer filter is exchanged.
1) Separate the rear panel from the station.
2) Unscrew the filter and clean the inner retina.
Fig.16 oil-discharging filter
Fig.14
