5
Enclosed Accessories:
1 Low pressure hose l = 3mt
1 High pressure hose 1 = 3 mt
1 Quick coupling low pressure
1 Quick coupling high pressure
1 Plastic bottle with 250 gr for fresh oil filling
1 Plastic bottles with 250 gr for old oil discharge
1 cable power supply
Accessories on request:
Detector’s lamp Art. 19CR export SI
Electronic leak search device TIF RX-1
O-Ring-Set 150 in Viton Art.47CR
O-Ring-Set 360 in Viton, Art. 47.3CR
Digital-Thermometer DT10K
Oil container for R134a, Art.21CR
Oil container for vacuum pump 1/2lt Art. AV68I
Data base and electrical switch plan + CD-Rom for A/C plants Art. 037.14DT
Retrofit kit for A/C plants Art. Retrofit 715
Leakage sealing set for A/C plants Art. Super Seal
TECHNICAL CHARACTERISTICS
Compressor:
Capacity:
Recovery capacity (liquid phase)
Hermetic with the recovered automatic oil
1/3 PS
400gr/min
Vacuum pump:
Capacity:
Vacuum grad:
One-step
4m
3
/h
7x10
2
Vacuum test: Automatically with alarm sound and message on display
Deposit bottle:
Capacity of freon:
With heating – two containers and security valve
18Kg
Exactness of scale:
+
/
-
10gr
Current Supply: 220v
Loudness: under 80dB (measured with sound level meter class 2 according
to norm IEC 651.804)
Tube length: 3 mt
Measurements of the devices:
Weight: Kg
CAP. 2 TECHNICAL SPECIFICATIONS
Fig.2
