IM-IBR17-49IN Issue 110
2.3 FT44 - Carbon steel
Sizes and pipe connections
DN15, DN20, DN25, DN40 and DN50
Horizontal traps:
Note the flow direction when facing the body is as follows:
-
DN15 to DN25 is left to right.
-
DN40 and DN50 is right to left.
Standard flanges - ASME B 16.5 Class 150 and 300 flanges are available with extended
face-to-face dimensions.
Fig. 2
FT44- C
FT44 DN40 and DN50
DN50 shown
FT44 DN15, DN20 and DN25
DN15 shown
