IM-IBR17-49IN Issue 120
Spare parts
The spare parts available are shown in heavy outline. Parts drawn in a grey line are not
supplied as spares.
Dowel
Steam lock
release assembly
19 + 21
2
2
3
20
Bimetallic air vent
assembly 17
18
