Spirax Sarco K Series User Manual

IM-S24-15 CH Issue 4
10
2.2 Pressure / temperature limits - ANSI KEA and LEA valves
KEA41 and KEA43 ANSI 150 or ANSI 300
Body design
KEA61 and KEA63 ANSI 150 or ANSI 300
conditions
KEA71 and KEA73 ANSI 125 or ANSI 250
LEA31 and LEA33 ANSI 125
KEA41 and KEA43 740 psi g @ 100°F
Maximum design
KEA61 and KEA63 720 psi g @ 100°F
pressure
KEA71 and KEA73 450 psi g @ 200°F
LEA31 and LEA33 200 psi g @ 150°F
Maximum design
KEA41, KEA43, KEA61 and KEA63 800°F
temperature
KEA71 and KEA73 450°F
LEA31 and LEA33 450°F
Minimum design
KEA41, KEA43, KEA71 and KEA73 14°F
temperature
KEA61 and KEA63 -20°F
LEA31 and LEA33 14°F
Standard packing PTFE chevron 482°F
PTFE soft seat (G) 400°F
Maximum operating
KEA41, KEA43,
temperature
KEA61 and KEA63
High temperature packing (H) 800°F
KEA71 and KEA73
LEA31 and LEA33
High temperature packing (H) 450°F
KEA41 and KEA43
ANSI 150 450 psi g
ANSI 300 1 125 psi g
Maximum cold ANSI 150 425 psi g
hydraulic test
KEA61 and KEA63
ANSI 300 1 100 psi g
pressure:
KEA71 and KEA73
ANSI 125 300 psi g
ANSI 250 750 psi g
LEA31 and LEA33 ANSI 125 300 psi g
Warning for valves fitted with bellows - Remove bellows before hydraulic testing is done
Maximum differential pressures: See relevant actuator Technical Information sheet
Key to charts on page 11:
The product must not be used in this region.
Graphite stem sealing is required for use in this region. Note: As standard the KEA,
KFA, KLA series two-port control valves are supplied with the PTFE stem sealing
option.
The product should not be used in this region or beyond its operating range as
damage to the internals may occur.
A - B Flanged ANSI 300 and screwed NPT (KEA41 and KEA61).
A - D Flanged ANSI 150.
A - C Flanged ANSI 250 and screwed NPT (KEA71).
A - E Flanged ANSI 125.
