IM-S24-15 CH Issue 4
22
5. Spare parts
Spare parts - KE43, KE61, KE63, KE71 and KE73 - DN15 to DN100
All spare parts available are shown in solid outline. Parts shown in broken line are not
supplied as spares.
Note: When placing an order for spares please indicate clearly the date code (found on the
label of the valve body e.g. C04), this will ensure that the correct spare parts are supplied.
Available spares
Actuator clamping nut A
PTFE gland seal kit for DN15 to DN50
(gasket, chevrons, spring, upper and lower bearings, B
'O' ring and gland nut)
PTFE gland seal kit for DN65 to DN100
Gland seal kits (gasket, chevrons, guide bush and spring)
B1
Graphite gland seal kit (H - high temperature seal)
(graphite stem seals, stuffing box gasket)
C
Note: The graphite gland seal kit is suitable
for stuffing box and bonnet designs.
Plug and stem Standard plug and stem assembly with bonnet gasket D, E
Soft seated plug and stem assembly with bonnet gasket D1, E
Note: Please state equal percentage, linear or fast opening plug when placing an order
Bonnet gasket (set of 3) E
Seat, seat gasket and bonnet gasket F, G, E
How to order spares
Always order spares by using the description given in the column headed 'Available spares'
and state the size and type of valve including the date code.
Example: 1 - PTFE gland seal kit for a Spirax Sarco DN25 KE73 two-port control valve.
Date coded C04.
How to fit spares
Full fitting instructions are given in the Installation and Maintenance Instructions supplied
with the spare.
