IM-S24-15 CH Issue 4
24
Spare parts - KEA series 6" and 8" (DN150 and DN200)
The spare parts available are shown in solid outline. Parts drawn in broken line are not
supplied as spares.
Note: When placing an order for spares please indicate clearly the date code (found on the
label of the valve body e.g. C04) this will ensure that the correct spare parts are supplied.
Available spares
Actuator clamping nut A
PTFE gland seal kit for DN15 to DN50
(gasket, chevrons, guide bush and spring)
B
Gland seal kits
Graphite gland seal kit
(H - high temperature seal option) C
(top support ring, graphite stem seal, bottom support ring)
Plug and stem
Standard plug and stem assembly with bonnet gasket D, E
Soft seated plug and stem assembly with bonnet gasket D, E
Note: Please state equal percentage, linear or fast opening plug when placing an order
Bonnet gasket (set of 3) E
Seat, seat gasket and bonnet gasket F, G, E
Soft seat seal kit (PTFE) soft seal and bonnet gasket H, E
How to order spares
Always order spares by using the description given in the column headed 'Available spares'
and state the size and type of valve including the date code.
Example: 1 - Seat, seat gasket and bonnet gasket for a Spirax Sarco 6" KEA73 two-port
control valve Cv 280 having flanged ANSI 250 connections. Date coded C04.
How to fit spares
Full fitting instructions are given in the Installation and Maintenance Instructions supplied
with the spare.
