Page #28 background image
IM-S24-15 CH Issue 4
28
Bellows sealed valve
Spares parts - KE series - DN15 to DN15 (½" to 8")
All available spare parts are identified below and clearly shown in Figure 11, page 29.
Note: when placing an order for spares please indicate clearly the date code (found on the
label of the valve body e.g. C04) this will ensure that the correct spare parts are supplied.
Available spares
PTFE gland seal kit for DN15 to DN50
(gasket, chevrons, spring, upper and lower bearings, B
'O' ring and gland nut)
PTFE gland seal kit for DN65 to DN100
Gland seal kits (gasket, chevrons, guide bush and spring) B1
Graphite gland seal kit (B1 only)
(graphite stem seals, stufng box gasket)
C
Note: The graphite gland seal is suitable
for stuffing box and bonnet designs.
Plug and pin
Standard plug J, K
Soft seated plug J1, K
Note: Please state equal percentage, linear or fast opening plug when placing an order
Seat and seat gasket F, G
Bonnet gasket (pack of 3) E
Bellows gasket (pack of 6) M
B1 Spindle/bellows assembly and plug pin K, L, M
B4 Spindle/bellows assembly and plug pin K, L
How to order spares
Always order spares by using the description given in the column headed 'Available spares'
and state the size and type of valve including the date code.
Example: 1 - Seat and seat gasket kit for a Spirax Sarco DN25 KE73B1 bellow sealed
two-port control valve. Date coded C04.
How to fit spares
Full fitting instructions are given in the Installation and Maintenance Instructions supplied
with the spare.
