30
5.4 Conversion of PN9000E to PN9000R (excluding the PN9400):
Note: Remove the actuator from the valve as described in Section 5.1.
-
Remove all short locking nuts and bolts (22 and 23).
-
Lubricate the threads of the three long hex. head screws with a PTFE based grease
before releasing the tension in the springs.
-
Loosen and remove the short housing screws and nuts (22, 23 and 24).
-
Holding each nut with a spanner, rotate the three long hex. head screws a few turns at
a time. Remove the screws and upper housing (2).
-
Remove the upper diaphragm housing and spring(s) (2 and 5).
-
Remove bolt and washer (21 and 28) while using a spanner to hold the actuator spindle (6).
-
Remove spacer (8), 'O' ring (9) and spring/s (5).
Note: orientation of the spacer and 'O' ring, must be as shown in Figures 13 and 14.
-
Place the diaphragm plate (3) over the springs (5), diaphragm (4) then replace the
bolt and washer (21 and 28), refer to Table 1 for correct tightening torques. It is
recommended that Loctite 243 be applied to the upper thread of the spindle (6) prior
to tightening.
