Spirax Sarco SX75 Series User Manual

7
4. ELECTRICAL WIRING
All screw terminals M3.5
Location pin
Plate screw
Wiring
protection plate
2
Rotate
downwards
1
Lift the plate to free
the location pin
2
Depress the plate to
engage the pin
1
Rotate
upwards
With eyelet
terminals
6.9 max.
With tinned wire
6
÷ 7
With fork
terminals
6.9 max.
Cable
section
wires
N°
0.25 ÷ 2.5
AWG
22 ÷ 14
2
1
2
Recommended
7
A ● T erminal board
B ● Freeing the terminals
D ● Protecting the terminal board
C ● Wirring connections
