Spirotech SPIROVENT - Introduction; Overview of the unit; Overview of the product variations

4 English User manual - 1.0
2 INTRODUCTION
2.1 Overview of the unit
1 Automatic air vent / manual air vent (SpiroTrap
only)
2 Lifting lugs
3Scum valve
4 Main body
5Safety plug
* Product variation. Refer to section 2.2.
2.2 Overview of the product variations
1Flange
2 Welded ends
3 Victaulic connection
4 Fixed bottom
5 Demountable bottom
6 Drain valve
7 Rotatable dry pocket (with magnet and drain valve)
1
2
3
4
*
*
*
5
1 2 3
4
5
6 7
