9
English
Purging and Priming the Spray Hose
1. Unlock the spray gun and turn the PRIME/SPRAY knob to
PRIME.
2.
PULL the trigger and aim the spray gun at the side wall of
a waste container.
If using oil-based materials, the
s
pray gun must be grounded while purging (see
warning below).
T
he spray tip SHOULD NOT
be attached to your spray
g
un when purging your
spray hose.
Keep hands clear from fluid stream.
Ground the gun by holding it against the
edge of a metal container while flushing.
Failure to do so may lead to a static electric
discharge which may cause a fire.
3. While pulling the trigger, switch the pump ON (l), AND
turn the PRIME/SPRAY knob to SPRAY. Hold the trigger
until all air, water, or solvent is purged from the spray
hose and material is flowing freely.
5. Lock the spray gun off. Make sure the saddle and
black seal are in place inside the tip guard nut (refer
to Components and Description
, page 5). Thread the
spray tip guard assembly onto the gun. Tighten by hand.
Begin
tightening
the tip at
this angle
. . .to achieve
the desired
spray angle
when tight.
4. Release trigger. Turn the PRIME/SPRAY knob to PRIME.
Turn the pump OFF (O). Trigger the gun into the waste
container to be sure that no pressure is left in the hose.
If the PRIME/SPRAY knob is still on SPRAY,
there will be high pressure in the hose and
spray gun until the PRIME/SPRAY knob is
turned to PRIME.
