Spring Air Systems Water Wash Ventilator Maintenance Manual 11/01
18
Hot Water Required Model S, B, & B-S
Ventilator
Length
Hot Water Flow
USGPM
Hot Water Flow
USGPM
Hot Water Flow
l/m
Hot Water Flow
l/s
feet meter @ 40 psi @ 60 psi @ 2.8 kg/cm2 @ 4.2 kg/cm2
3.0 914 2.4 2.8 13.2 16.2
3.5 1067 3.1 3.8 17.3 21.2
4.0 1279 3.1 3.8 17.3 21.2
4.5 1372 3.1 3.8 17.3 21.2
5.0 1524 3.1 3.8 17.3 21.2
5.5 1676 3.7 4.5 20.5 25.1
6.0 1829 3.7 4.5 20.5 25.1
6.5 1981 4.3 5.3 24.1 29.5
7.0 2131 4.3 5.3 24.1 29.5
7.5 2286 4.9 6.0 27.3 33.4
8.0 2438 4.9 6.0 27.3 33.4
8.5 2591 5.5 6.7 30.5 37.3
9.0 2743 5.5 6.7 30.5 37.3
9.5 2896 6.7 8.2 37.3 45.7
10.0 3048 6.7 8.2 37.3 45.7
10.5 3200 7.3 8.9 40.5 50.0
11.0 3353 7.3 8.9 40.5 50.0
11.5 3505 7.9 9.7 44.2 54.0
12.0 3658 7.9 9.7 44.2 54.0
12.5 3810 8.5 10.4 47.4 57.9
13.0 3962 8.5 10.4 47.4 57.9
13.5 4115 9.2 11.3 51.4 63.0
14.0. 4207 9.2 11.3 51.4 63.0
14.5 4420 9.8 12.0 54.6 66.8
15.0 4772 9.8 12.0 54.6 66.8
Chart No.1
Cold Water Required Model S, B, & B-S
Ventilator
Length
Cold Water
Flow
USGPM
Cold Water
Flow
l/s
Ventilator
Length
Cold Water
Flow
USGPM
Cold Water
Flow
l/s
feet meter @ 10 psi @ 0.7
kg/cm2
feet meter @ 10 psi @ 0.7
kg/cm2
3.0 914 0.35 1.32 9.5 2896 0.91 3.44
3.5 1067 0.35 1.32 10.0 3048 0.98 3.71
4.0 1279 0.42 1.59 10.5 3200 1.05 3.97
4.5 1372 0.49 1.85 11.0 3353 1.05 3.97
5.0 1524 0.49 1.85 11.5 3505 1.12 4.24
5.5 1676 0.56 2.12 12.0 3658 1.19 4.50
6.0 1829 0.63 2.38 12.5 3810 1.19 4.50
6.5 1981 0.63 2.38 13.0 3962 1.26 4.77
7.0 2131 0.70 2.65 13.5 4115 1.33 5.03
7.5 2286 0.77 2.65 14.0. 4207 1.33 5.03
8.0 2438 0.77 2.91 14.5 4420 1.40 5.30
8.5 2591 0.84 2.91 15.0 4772 1.47 5.56
9.0 2743 0.91 3.44
Chart No.2
