Operators manual MODEL 80XX Planter
page 138 of 173
Attachments
4-Wheel Caster Locks
Pos. Quantity Part # Description
132405 ASSY,WHEEL LOCK,2004
1 1 502473 SCREW,SET,SQR,HD,3/8-16 x 2"
2 1 501809 NUT,HEX,3/8"-16UNC
3 1 132404 WHEEL LOCK HOUSING,2004
4 1 181716 ROLLER,PLUNGER STOP,WHEEL LOCK, PLANTER
5 1 981446 SPRING,COMPRESSION,1-1/4"OD x 4"LONG
6 1 181722 PLUNGER,WHEEL LOCK PLANTER
7 1 181882 DISK,WHEEL,LOCK PLUNGER
8 1 502601 BOLT,SHOULDER,SOCKET HEAD,3/8" X 1-1/2"
9 1 502438 PIN,ROLL,5/16" x 2-1/2" LONG
11 1 501991 FITTING,GREASE,1/4"-28UNF STRAIGHT 641B
PARTS
