Status/ Diagnostics
The Status/ Diagnostics section allows you to monitor specific sections of the machine.
The following describes each icon’s meaning:
This icon indicates an okay, open circuit status.
This icon indicates an okay, closed circuit status.
This icon indicates a short circuit to ground.
This icon indicates a broken wire.
