Operators manual MODEL 80XX Planter
page 150 of 173
Attachments
Chemical Box Drives
Pos. Quantity Part # Description
1 1 173367 SHLD,CHEM BOX,HYD DRIVE
2 1 193334 SHIELD,CHEM DRIVE 80XX,2006
3 4 981250 KNOB,CLAMPING,W/STUD 3/8"-16x1" 5993K41
4 1 CHN,RLR,60
5 1 881054 SPRCKT,H60BS36 x 1“ BORE
6 4 881079 IDLER,60,PITCH,5/8" BORE 15 TOOTH #709
7 3 501900 COLLAR,SHAFT,SET,SCREW,5/8"
8 1 172064 PLATE IDLER ADJUSTER
9 1 231180 BRNG,BRONZE,FLNGD,5/8"IDx5/8"LG 6338K425
10 1 981456 SPRING,EXTENSION,3/4" x.085" WIREx5"LNG
11 1 G00003 CHN,LINK,3/16,9LNK
12 2 172206 SPACER,TUBE IDLER MECHANICAL DRIVE
13 1 502446 PIN,LINCH,5/16"OD x 1-9/16"LG W/RING
14 1 173366 SHLD,BRACKET
15 1 193335 FRAME,CHEM DRIVE,80XX-2006
16 1 881287 SPRCKT,60A12x1-1/4" BORE 2003 MDL
17 1 881288 SPRCKT,60A13x1-1/4" BORE 2003 MDL
18 1 881289 SPRCKT,60A14x1-1/4" BORE 2003 MDL
19 1 881290 SPRCKT,60A15x1-1/4" BORE 2003 MDL
20 1 881291 SPRCKT,60A16x1-1/4" BORE 2003 MDL
21 1 881292 SPRCKT,60A17x1-1/4" BORE 2003 MDL
22 1 881293 SPRCKT,60A18x1-1/4" BORE 2003 MDL
23 1 881294 SPRCKT,60A19x1-1/4" BORE 2003 MDL
PARTS
