Operators manual MODEL 80XX Planter
page 56 of 173
Status/ Diagnostics
(Continued from the previous page)
Press the scroll down button
once to view the next display
Press the scroll down button
once to view the next display
(Continued on the next page)
This section displays the hydraulic motor status.
This section displays the impulses from the belt, wheel,
the radar, and the working position sensor status.
CP600 CONTROL BOX
To Next Page
