Operators manual MODEL 80XX Planter
page 84 of 173
Standard Parts
Feed Chains
PARTS
Pos. Quantity Part # Description
1 1 352390 CHN,HOOK,7"x1"PITCHx72 PITCHES W/FLITES
2 1 502305 BOLT,HEX,HD,5/8"-11UNC x 10" GR 5
3 10 501371 WASHER,FLAT,5/8" (SAE)
4 2 131807 WELD,IDLER ADJUSTER (SMALL)
5 2 M00651 SPACER,TAKE-UP,SEED FEED CONVEYOR
6 6 351309 STANDOFF,RLR,BLTD,CHN,5/8"x1-1/4" #750
7 6 351314 RLR,BLTD,CHN,5/8"x4" RUBBER
8 1 171994 TUBE,SPACER SEED FEED CONVEYOR
9 1 501814 NUT,HEX,5/8"-11UNC
10 4 501129 BOLT,HEX,HD,5/8"-11UNC x 3" GR 5
11 4 501935 WASHER,LOCK,SPLIT,5/8"
12 4 501814 NUT,HEX,5/8"-11UNC
13 2 501269 WASHER,FLAT,1/2" (SAE) ZINC PLATED
14 1 192600 SHAFT CHAIN DRIVE HOPPER MDL 8060
15 2 231157 HOUSING,BRNG,2HOLE,52MM,FLANGETTE PLATED
16 2 231070 BRNG,INSERT,1" BORE SPHR OD
17 1 050015 SHAFT COUPLING
18 1 602108 MTR,HY,12.5CUIN,1"KEY,SAE-A,RS-SERIES
19 1 602120 VALVE,CARTRIDGE,2-WAY POPPET
