SPECIFICATIONS: Electrical Schematic
Figure 6A
Models: FLX 1.1, FLX 1.2 (115V/1PH/60Hz)
NL E
Customer's installation
115V/1PH/60Hz
MC1
S1
M2
L1
N1
S0
F0
(16A)
M1
CS
C
S
M
3
5
R
S2
CR
4
SOL.
S3
1
DIP SW
2 3 4
AC IN1
COMP1
ALARM1
DRAIN
COM.
N.O.
N.C.
COM
ON
R1
S1
FG
S2
R2
COM
ON
COM
RBRA
TS1 TS2
DRAIN
TRAP1
MC1
8 9 10 8
N1 L1
PCB
LEGEND
M1: Refrigerant Compressor
M2: Fan Motor MC1: Magnetic Contactor
CR: Running Capacitor
CS: Starting Capacitor (FLX 1.2 ONLY)
R: PTC Relay
S1: Switch “On-Off” S2: Overload Protector S3: High Pressure Switch
TS1: Temperature Sensor 1 TS2: Temperature Sensor 2 SOL: No Loss Drain Valve PCB: Control Board
S0: Main Switch (Customer’s installation)
F0: Main Fuse (Customer’s installation)
