SPX Pneumatic Products IBP Series User Manual

52 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

IBP Series

Blower Purge Desiccant Compressed Air Dryer

FORM NO.: 3158144 REVISION: 07/2014 READ AND UNDERSTAND THIS MANUAL PRIOR TO OPERATING OR SERVICING THIS PRODUCT.

INSTRUCTION MANUAL

MODELS

RATED

FLOW

MODEL

REFERENCE

IBP500

IBP600

IBP750

IBP900

IBP1050

500 SCFM

600 SCFM

750 SCFM

900 SCFM

1050 SCFM

500

600

750

900

1050

IBP1300

IBP1500

IBP1800

IBP2200

IBP2600

1300 SCFM

1500 SCFM

1800 SCFM

2200 SCFM

2600 SCFM

1300

1500

1800

2200

2600

IBP3200

IBP3600

IBP4300

3200 SCFM

3600 SCFM

4300 SCFM

3200

3600

4300

Questions and Answers:

D
Daniel WilliamsAug 18, 2025
What to do if SPX Pneumatic Products IBP Dehumidifier shows a High Humidity Alarm?
- A
  Anthony MorganAug 18, 2025
  To troubleshoot a High Humidity Alarm on the SPX Dehumidifier, consider these potential causes: * The desiccant bed may be overloaded. Check the inlet air flow rate, temperature, and pressure. If the flow and temperature are higher than the design specifications, or the pressure is lower, it can overload the dryer. * The dew point sensor or monitor could be damaged or defective. Inspect the sensor for any physical damage and verify the operation of the monitor/sensor. Replace if necessary. * There may be a loss of desiccant drying capacity. Check the filter elements and drains for contamination due to improperly filtered inlet air. Repair or replace as necessary. Also, consider if the desiccant's useful life has been exceeded.
D
davislukeAug 23, 2025
Why does my SPX Pneumatic Products IBP show a Heater Over-Temperature Alarm?
- J
  James RossAug 23, 2025
  If your SPX Dehumidifier displays a Heater Over-Temperature Alarm, it could be due to: * Insufficient purge gas flow. Check for purge blockage or temperature sensor failure. * Temperature sensor failure. Repair or replace the sensor as required.
T
thomasjasonAug 26, 2025
Why does my SPX Pneumatic Products IBP show a Heater Low-Temperature Alarm?
- C
  Christopher MorrisAug 26, 2025
  If your SPX Dehumidifier displays a Heater Low-Temperature Alarm, it could be due to: * A heating malfunction caused by heater failure or heater contactor failure. Replace the heater or heater contactor. * Temperature sensor failure. Repair or replace the sensor as required.
C
Charles WongSep 3, 2025
How to fix SPX Pneumatic Products IBP when indicator lights are not illuminated?
- K
  Kathleen ByrdSep 3, 2025
  If the indicator lights on your SPX Dehumidifier are not illuminated, here are some potential causes and solutions: 1. No power to the unit: Check the voltage at the terminal board. 2. Loss of power supply to (or at) the dryer’s electrical disconnect switch or breaker: Check if the disconnect switch or breaker is closed. If a tripped breaker or blown fuse is found, investigate and fix the cause. 3. Blown fuse: Replace the fuse. 4. Board malfunction: Replace the board.
A
Amber BrennanSep 6, 2025
What causes excessive pressure drop in SPX Dehumidifier?
- A
  Adriana MyersSep 6, 2025
  If your SPX Dehumidifier is experiencing excessive pressure drop, it may be due to: 1. Dirty inlet/outlet screens on the desiccant towers. Clean the screens, following the desiccant removal instructions in the Maintenance section. 2. Excessive flow rate. Check the flow rate of the inlet air and reduce it to the design flow rate.
A
Amanda BrownSep 8, 2025
What does it mean when SPX Pneumatic Products IBP Dehumidifier displays Temperature Under-Range or Over-Range Alarm?
- S
  Sara GonzalezSep 8, 2025
  If the SPX Dehumidifier displays a Temperature Under-Range or Temperature Over-Range Alarm for either the Left Tower or Right Tower, it could be due to: * Tower temperature sensor failure. Check the temperature circuit for continuity. Repair or replace as necessary.
S
shawnbartlettSep 10, 2025
What causes Blower Motor Overload Alarm on SPX Pneumatic Products IBP Dehumidifier?
- B
  Brittany AlvarezSep 12, 2025
  If your SPX Dehumidifier displays a Blower Motor Overload Alarm, it could be due to: * Restricted or blocked purge air flow. Check the intake filter on the blower and clean or replace the filter element. * Line failure. Check the voltages and currents in the motor circuit.
T
Taylor SantanaSep 13, 2025
What does Energy Management Under-Range or Over-Range Alarm mean for SPX Dehumidifier?
- R
  Richard GomezSep 13, 2025
  If the SPX Dehumidifier displays an Energy Management Under-Range Alarm or Energy Management Over-Range Alarm, it may be caused by: * Energy Management sensor failure. Check the circuit for continuity. Repair or replace as necessary.
