SPXFLOW Colloid Mill - Colloid Mill Fluid Head

95-03028
09/201918
Waukesha Cherry-Burrell
®
Brand Colloid MillMaintenance
DP100-005
39
38
37
30
44
46,
47
45
28
29
30
23
26 25
30
27
23
2943
32
34
40
42
41
35
30
31
33
36 24
23
Colloid Mill Fluid Head
NOTE:
Torque rotor nuts
to 75 ft-lb
Used to set adjusting
ring at minimum
setting of 0.010”
Used to hold
adjusting ring
setting
NOTE:
Body rotor
clearance starts
at 0.101” and
ends at 0.220”
in increments of
0.010”
