SPXFLOW Colloid Mill - Colloid Mill Unit Dimensions

7
95-03028
09/2019
Waukesha Cherry-Burrell
®
Brand Colloid Mill Introduction/Specications
4.31 [110]
8.63 [219]
10.00 [254]
6.00 [152]
12.00 [305]
1.50 [38] TYP.
8.56 [217]
13.75 [349] MIN.
14.88 [378] MAX.
9.38 [238] MIN.
10.51 [267] MAX.
17.44 [443]
26.81 [681] AS SHOWN, WITH STATOR ALL THE WAY IN
27.94 [710] WITH STATOR ALL THE WAY OUT
3.00 [76]
Ø1.50 [38]
1.65
[42]
Ø.56 [14]
.38 KEY [10]
2"-8 IMDA INLET
2"-8 IMDA
OUTLET
1/4-18 NPT PIPE
NIPPLE SEAL
FLUSH OUTLET
1/4-18 NPT PIPE
NIPPLE SEAL
FLUSH INLET
DP100-011
Figure 1
Colloid Mill Unit Dimensions
F
C B
J
X
A
G
2"-8 IMDA
Y
D
T
E
DP100-012
NOTE: The pump is shimmed to “D” height.
Figure 2
Unit
Size
A B C D E F G J T X Y
15 HP 51.57
(1310)
41.00
(1041)
2.88
(73)
6.25
(159)
4.75
(121)
8.50
(216)
17.00
(432)
17.69
(449)
17.00
(432)
9.40
(239)
6.00
(152)
20 HP 53.32
(1354)
41.00
(1041)
2.88
(73)
6.25
(159)
4.75
(121)
8.50
(216)
17.00
(432)
17.69
(449)
17.00
(432)
9.40
(239)
6.00
(152)
25 HP 54.20
(1377)
41.00
(1041)
2.88
(73)
7.00
(178)
4.75
(121)
8.50
(216)
17.00
(432)
21.90
(556)
17.00
(432)
9.40
(239)
6.00
(152)
Dimensions shown in IN (mm)
