Lens Fixed
Sensor 0.3 MP
Resolutions 640 x 480 or 320 x 240
Frame rates (frames per second) 20 fps (high) or 6 fps (low)
Video qualities High, medium, low
Low-light sensor sensitivity 6.8 V/lux-sec
Sensor viewing angle H/V 62°
Memory card support Max 200GB microSD card
Memory usage High frame rate: 45 min./GB
Low frame rate: 3 hr./GB
Microphone Speech-grade
Battery handling Non-removable
Battery type Rechargeable 800 mAh 3.7V Li-ion
Current consumption 80mA
Storage and operating temperature range 32 to 113°F (0 to 45°C)
File format AVI
Port Mini-B USB 2.0
Slot MicroSD/HC/XC
Internal memory None useable
Size (D x W x H) 3" x 1.7" x .75" (7.6 x 4.3 x 1.9 cm)
Weight 1.6 oz. (46 g)
TROUBLESHOOTING AND FAQS
64- to 200GB microSD Card Support
If one of these high-capacity cards is not recognized by the Z12, you’ll need to
properly format it. If the card has not been used before, formatting it won’t wipe out
any data. But if the card has been in use, keep in mind that any data stored on the
card will be lost during formatting.
Fully insert the up to 200GB microSD card into the camera’s memory slot until a click
is heard and connect the camera to your PC using the included USB cable.
Zetta Widget Software Loads But Won’t Operate
The camera must be connected and recognized by your computer for you to use
the software. Otherwise, options will be grayed out and every screen will show an
unplugged icon in red along with the phrase DVR Disconnected.
SPECIFICATIONS
SPYTEC Z12 INTELLIGENT SECURITY CAMCORDER USER GUIDE 16
