SRAM Elixir 5 User Manual

17
elixir 5 brake caliper overhaul
4
Use an 8 mm open end wrench to remove the compression
fitting. Pull the brake hose and compression fitting from the
caliper body.
Brake fluid will leak, so hold the caliper over a container
to catch the fluid.
5
Use a 5 mm hex to remove the caliper body bolts .
6
Separate the caliper body halves and open the caliper
assembly.
8 mm
5 mm
