Page #47 background image
47
3
Adjust
Juster Reglare
Reguluj Nastavit Προσαρμογή
Close the clamp on
the syringe at the
brake lever.
Åbn klemmen på sprøjten
ved bremsegrebet.
Închideți clema de pe
seringa manetei de frână.
Zamknij zacisk na
strzykawce na dźwigni
hamulca.
Uzavřete svorku na
stříkačce u brzdové páčky.
Κλείστε το σφιγκτήρα
στη σύριγγα στη μανέτα
των φρένων.
Use a toe strap or your hand
to hold the lever blade to
the bar. Do not release the
lever until instructed to do
so.
Brug en tårem eller din hånd
til at holde bremsegrebet
fast mod styret. Slip ikke
bremsegrebet før du får
instruks om det.
Ţineţi maneta strânsă spre
ghidon cu ajutorul unei
curea pentru ratrape sau cu
mâna. Nu eliberaţi maneta
până când instrucţiunile nu
o indică.
Za pomocą paska na
palce lub własną ręką
przyciągnij rączkę dźwigni
do kierownicy. Nie
zwalniaj dzwigni, zanim nie
otrzymasz takiej instrukcji.
Rukou nebo pomocí
palcového popruhu držte
páčku u řídítek. Páčku
neuvolňujete dříve, než
určují pokyny.
Χρησιμοποιήστε ένα
κορδόνι παπουτσιών
ή το χέρι σας για να
κρατήσετε τη λεπίδα
της μανέτας κλεισμένη
πάνω στην μπάρα. Μην
απελευθερώσετε τη
μανέτα μέχρι να σας
δοθεί η αντίστοιχη
οδηγία.
2

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SRAM GUIDE RE and is the answer not in the manual?

SRAM GUIDE RE Specifications

General IconGeneral
TypeHydraulic Disc Brake
Caliper Design4-Piston
Lever MaterialAluminum
AdjustmentReach Adjust
Brake FluidDOT 5.1
Pad MaterialSteel-backed Organic
Piston MaterialPhenolic Plastic
Intended UseEnduro, Downhill
Rotor CompatibilityCenterLine Rotors
Hose Length950mm (front), 1800mm (rear)
