10
Exploded View - 2019-2020 Sektor™ RL - DebonAir™ - 130 mm - 150 mm
Exploded View - 2019-2020 Sektor™ RL - DebonAir™ - 130 mm - 150 mm
Retaining screw
Compression
adjuster knob
Detent spring
Crown
Compression damper
Dust wiper seal
Foam ring
Rebound damper piston
Rebound
damper shaft
Rebound damper seal head
Retaining
ring
Maxle™ Lite
Crush washer
Crush washer
retainer
Bottom bolt
Rebound adjuster knob
Steerer tube
Air cap
Air valve
Air spring
top cap
Upper tube
Air spring piston
Top out bumper
All-Travel spacer (optional)
Retaining ring
Retaining washer
Floating seal head
Air spring shaft
Air Spring Assembly
Compression Damper
Assembly
Rebound Damper
Assembly
Brake hose guide
Lower leg
Sag o-ring
Wave spring
Arch
Base plate
Bottomless Token(s)™
(optional)
(32 mm black)
Bottom out bumper
2019 Sektor RL R
Retaining screw
Remote spool lower
Remote cable
stop collar
Set screw
Remote spool upper
2020 Sektor RL R
Retaining screw
Remote cable
stop collar
Set screw
Set screw
Remote spool
